The elmass® broaching tool simplifies slotting

Type 06

Bore Ø Keyway width Keyway length*
from 6 to 10 mm 2 – 3 mm 80 mm max.

Type 11

Bore Ø Keyway width Keyway length*
from 11 to 22 mm 4 – 5 – 6 – (7) mm 100 mm max.

Type 24

Bore Ø Keyway width Keyway length*
from 24 to 50 mm 8 – 10 – 12 – 14 mm 150 mm max.

Type 55

Bore Ø Keyway width Keyway length*
from 55 to 150 mm 16 – 36 mm 250 mm max.

This overview is only a small fraction of standard tools.

For example, if you require a different guide bush, cutter width of cutting length, please contact us or a dealer.
